1.0 Mm Pitch FPC Connector H2.0mm Bottom Contact ZIF 4 Pin FFC Connector

Product Categories

Shenzhen Xietaikang Precision Electronic Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

1.0 Mm Pitch FPC Connector H2.0mm Bottom Contact ZIF 4 Pin FFC Connector

Ask Lasest Price
Brand Name :	XTKCONN
Model Number :	FPC-T2T1-0020-B**
Certification :	CE,SGS,ROHS,ISO9001
Price :	Negotiable price
Payment Terms :	L/C, T/T,Payyal
Supply Ability :	4KK pcs
Delivery Time :	5-7 days

Add to Cart

Product Details
Company Profile

1.0 Mm Pitch FPC Connector H2.0mm Bottom Contact ZIF 4 Pin FFC Connector

1.0 mm Pitch FPC Connector 4 Pins H 2.0mm BottomContact ZIF Type Soldering

FPC/FFC connectors provided by Xietaikang are narrow-pitches and low-profile connectors contributing to space-saving that are optimum for compact telecommunication apparatus and products supporting equipment requiring high-speed data transmission , and a wide variety of product types featuring convenient one-touch locking function (flip-type locking), sliding ZIF and etc. are provided for achieving customers' requests.

Description

1.0mm pitch type connectors modified from 0.5mm pitch ones. (Only even-numbered pins are inserted.)Wide variations in stacking height and pin count are provided.For details, please refer to a 0.5mm-pitch type page of each Series.

Pitch	1.0mm
Height	2.0mm
Mounting Type	SMT/ZIF
No. Of Positions	4-40pin
Contact Location	Bottom contact
Type	Front lock
Current Rating	0.5A/Pin Max
Voltage Rating	50V AC/DC MAX
Withstanding Voltage	500V AC,1min
Cover Material	LCP UL94V-0 black
Housing	LCP UL94V-0 Natural
Terminal/Contact	Phosphor bronze
Plating	Tin-plating
Operation Temperature	-40℃ to +85℃
Lead Time	7-10 working Days

1.0 Mm Pitch FPC Connector H2.0mm Bottom Contact ZIF 4 Pin FFC Connector

Typical Applications

Audio Players,

Printers / Copiers,

Industrial Equipment,

Medical Equipment etc.

Primary Competitive Advantages

Small orders accepted

Factory direct export

With 20 years of professional production experience as a manufacturer of precision connectors

Free samples is available

Prompt delivery

Green product

Strong researching and developing team

Experienced staff

ISO9001,ROHS
